1316880000 ZDU 2.5N OR Z-Series 1-Tier Terminal, 800 VAC, 24 A, 16 to 12 AWG Wire, Snap-On Mounting
| Branch Name | Available |
|---|
Weidmuller, 1316880000, Terminal, 1-Tier, Series: Z-Series, 800 VAC, 24 A, 16 to 12 AWG Wire, 10 mm Wire Strip Length, Snap-On Mounting, Tension Clamp Connection, -50 to 120 deg C, Wemid, Orange, 50.5 mm H x 5.1 mm W x 38.5 mm D Dimensions
| Color | : | Orange |
| Connection Type | : | Tension Clamp |
| Dimensions | : | 50.5 mm H x 5.1 mm W x 38.5 mm D |
| Material | : | Wemid |
| Series | : | Z-Series |
| Temperature Rating | : | -50 to 120 deg C |
| Type | : | 1-Tier |
| Wire Strip Length | : | 10 mm |
| Voltage Rating | : | 800 VAC |
| Amperage Rating | : | 24 A |
| Wire Size | : | 16 to 12 AWG |
| Mounting Type | : | Snap-On |
