1542530000 DRMKIT 24VAC 4CO LD/PB D Universal Range Relays with, 5 A, 4 Pin, CO Contact, 24 V Coil
| Branch Name | Available |
|---|
Weidmuller, 1542530000, Relays, Universal Range, Series: D, 5 A, 1.0 to 1.2 VA Power, 0.1 Hz Frequency, 24 V Coil, CO Contact Form, 24 VAC Contact, 4 Pins, TS32/TS35 DIN Rail Mounting, Screw Terminal, LED Display, IP20 Enclosure, -40 to 55 deg C, 3.146 in H x 1.071 in W x 2.63 in D Dimensions
| Contact Rating | : | 24 VAC |
| Dimensions | : | 3.146 in H x 1.071 in W x 2.63 in D |
| Display Type | : | LED |
| Enclosure Type | : | IP20 |
| Frequency Rating | : | 0.1 Hz |
| Mounting Type | : | TS32/TS35 DIN Rail |
| Power Rating | : | 1.0 to 1.2 VA |
| Series | : | D |
| Temperature Rating | : | -40 to 55 deg C |
| Terminal Type | : | Screw |
| Type | : | Universal Range |
| Amperage Rating | : | 5 A |
| Number of Pins | : | 4 |
| Contact Form | : | CO |
| Coil Voltage | : | 24 V |
