BRP120DFC Type BR Dual Function AF/GF Circuit Breaker, 120/240 VAC, 20 A, 10 kA Interrupt, 1 Poles
| Branch Name | Available |
|---|
Sold as: Pack of EACH
EATON residential BR circuit breakers are used in load centers, panelboards or similar devices. They are made for a wide range of applications and include BR 1 in circuit breakers and accessories for BR-style load centers; arc fault circuit interrupters (AFCI) and ground fault circuit interrupters (GFCI).
EATON AF/GF Circuit Breaker, Type BR Dual Function, 120/240 VAC, 20 A, 10 kA Interrupt, 5 mA Trip, 1 Pole, Plug-On Connection, 2.9 in L x 2.9 in W x 0.9 in H Dimensions
| Connection Type | : | Plug-On |
| Dimensions | : | 2.9 in L x 2.9 in W x 0.9 in H |
| Trip Range | : | 5 mA |
| Type | : | Type BR Dual Function |
| Voltage Rating | : | 120/240 VAC |
| Amperage Rating | : | 20 A |
| Interrupt Rating | : | 10 kA |
| Number of Poles | : | 1 |
