DSD925 2-Circuit 2-Position Factory Sealed Heavy Duty Control Station Selector Switch, 600 VAC, 10 A, 4NO-2NC Contact, 1 Operator, NEMA 3/7B/7C/7D/9E/9F/9G NEMA Rating
| Branch Name | Available |
|---|
Sold as: Pack of EACH
Crouse-Hinds series DSD explosionproof cover and device sub-assemblies are for use with EDSCM modular control device bodies and EDS/EDSC back boxes.
Crouse-Hinds Control Station Selector Switch, 2-Circuit 2-Position Factory Sealed Heavy Duty, Series: DSD, 600 VAC, 10 A, 1 Operator, 4NO-2NC Contact Configuration, Maintained Contact Mode, Thread Connection, NEMA 3/7B/7C/7D/9E/9F/9G NEMA Rating, Feraloy Iron Alloy, Electro-Galvanized/Aluminum Acrylic Painted
| Connection Type | : | Thread |
| Contact Mode | : | Maintained |
| Finish | : | Electro-Galvanized/Aluminum Acrylic Painted |
| Material | : | Feraloy Iron Alloy |
| Series | : | DSD |
| Type | : | 2-Circuit 2-Position Factory Sealed Heavy Duty |
| Voltage Rating | : | 600 VAC |
| Amperage Rating | : | 10 A |
| Contact Configuration | : | 4NO-2NC |
| Number of Operators | : | 1 |
| NEMA Rating | : | NEMA 3/7B/7C/7D/9E/9F/9G |
