Inlet power shore 2-pole non-metallic 50A 125V white

Manufacturer: Hubbell Wiring Devices | Catalog # HBL503NM | Electrozad South Part # 99747
*Call For Price*
Log in or register to view your price, purchase history, and more!
Usually ships within 12 to 18 days
Specification Sheet Product Catalog Page Installation / Instruction Manual Technical Drawing Manufacturer Warranty
Ship-to-shore power inlet device. In either rugged thermoplastic or corrosion resistant stainless steel-to add the finishing touch to a boat going into production or to modernize a boat that seen many seasons of use. Both the gleam. Stylized non-metallic shore power inlet has UV resistant white. Centrex cover which makes unit weatherproof when completely closed. Interior has easy to wire terminals. Mounting holes are 2-3/8 inch on centers and match existing mounting patterns. Mounting screws and gasket included.

Technical Information

Amperage
50 A
Applications
Marine Wiring Devices
Conductor Size
6 AWG
Current
50 A
Dielectric Strength
Withstands 3000V Minimum in
Material
Thermoplastic
Mounting Type
Screw
Number of Phases
1
Number of Poles
2
Number of Wires
3
Rating
125 V
Size
Standard Sized
Standard
UL
TC Connection
Pressure Screw Terminals
Temperature Rating
-40 degrees C
Type
Hull Mount, Single, Locking, Marine Grade
Voltage
125 V
Wattage
6250 W
Wire Count
3
Wire Size
6 AWG

Manufacturer Information

Brand
Hubbell Wiring Device Kellems
Sub Brand
Twist-Lock®

General Product Info

12-Digit UPC
783585519487
Color
White
Environmental Conditions
Watertight
GTIN
00783585519487
Product UPC
78358551948
Weight
0.9 lb

Dimensions

Height
3.5 in
Length
9.100 in
Width
4.800 in

Certifications & Compliance

Country of Origin
Puerto Rico
Overview
  • Neoprene gasket on underside of cover for sealing
  • Self-closing Friction Tight Cover
  • New quick connect with backwards compatibility
  • Rear enclosure is nickel plated for corrossion resistance
