Receptacle locking flanged outlet 4P 5W 277/480V 30AMP white

Manufacturer: Leviton Manufacturing | Catalog # 2826 | Electrozad South Part # 81673
*Call For Price*
Log in or register to view your price, purchase history, and more!
Usually ships within 12 to 18 days
Specification Sheet MDM SAFETY DATA SHEET MSDS | SDS Safety Sheet Technical Drawing
Leviton's industry leading locking devices, such as our black white line of industrial grade plugs and connectors and our V-0-Max line of industrial grade flush receptacles, offer superior performance, long lasting reliability and other features that are backed by a lifetime warranty.

Technical Information

Amperage
30 A
Applications
Commercial
Body Material
Nylon
Connection Type
Back Wired
Contact Material
Brass
Device Type
Locking Flanged Outlet
Dielectric
2000 V
Dielectric Strength
2000 (Min.)
Face Material
Nylon
Flamability Class
Rated V-2 Per UL 94
Grounding
Grounding
Horsepower
10 hp
Material
Nylon
Mounting Type
Flange
NEMA
WD-6
Number of Phases
3
Number of Poles
4
Number of Wires
5
Operating Temperature
-40 degrees C
Rated Insulation Voltage
2000 V
Screw Material
Brass,Brass
Screw Size
10-32,8-32
Size
33 Dia. IN
Standard
ANSI C-73
TC Connection
Back & Side Wired
Temperature Rating
-40 to 60 degrees C
Temperature Rise
200 %
Terminal Size
14-8 AWG
Termination Type
Back Wire
Type
Locking
Voltage
277/480 V
Wire Count
5
Wire Size
16 - 8 AWG

Manufacturer Information

Brand
Leviton
Sub Brand
Locking Devices

General Product Info

12-Digit UPC
078477806593
Color
White
Environment
Dry
Environmental Conditions
Flammability (Rated V-2 Per UL94)
GTIN
00078477806593

Dimensions

Warranty Length
Lifetime Limited

Certifications & Compliance

Country of Origin
Mexico
