Terminal ring copper mtlc 12-10AWG 1/4in Sta-Kon

Manufacturer: ABB | Thomas & Betts | Catalog # RC10-14 | Electrozad South Part # 64316
*Call For Price*
Log in or register to view your price, purchase history, and more!
Usually ships within 12 to 18 days
Specification Sheet Product Brochure Product Catalog Page Technical Drawing
Sta-Kon® non-insulated ring terminal which is constructed of electrolytic copper for high conductivity. It can be installed with crimping tools having a single indentor or double indentor. Wire range identification on the tongue of each terminal.

Technical Information

Conductor Size
12-10 AWG
Flamability Class
Rated V-2 Per UL94
Insulation Material
Nylon
Insulation Type
Insulated Nylon
Material
Copper
Standard
UL E9809
Stud Size
1/4 in
Temperature Rating
105 degrees C
Terminal Type
RC
Type
Long Sleeve
Voltage
600 V
Wire Size
12 - 10 AWG

Manufacturer Information

Brand
ABB
Sub Brand
Sta-Kon®

General Product Info

12-Digit UPC
786210804422
Color
Yellow
Finish
Tin Plated
GTIN
05414363159087
Used With
Round Conductors

Dimensions

Height
3 in
Thickness
.04 in
Width
1.3 in
