LKG RCPT, IG, 20A 125V, L5-20R, OR, ST

Manufacturer: Hubbell Wiring Devices | Catalog # IG2310ST | Electrozad South Part # 420800
*Call For Price*
Log in or register to view your price, purchase history, and more!
Usually ships within 12 to 18 days
Specification Sheet Product Brochure Product Catalog Page Installation / Instruction Manual Technical Drawing Manufacturer Warranty
Locking Devices, EdgeConnect™, Isolated Ground Industrial, Flush Receptacle, 20A 125V, 2-Pole 3-Wire Grounding, L5-20R, Spring Termination, Orange

Technical Information

Current
20 A
Horsepower
1 hp
Material
Nylon
Number of Poles
2,2
Number of Wires
3,3
Wire Size
16-8 AWG

Manufacturer Information

Brand
Hubbell Wiring Device-Kellems

General Product Info

12-Digit UPC
783585730370
Color
Orange
GTIN
00783585730370
Product UPC
78358573037
Weight
0.25 lb

Dimensions

Height
1.70 in
Length
3.28 in
Width
1.24 in

Certifications & Compliance

Country of Origin
China
Overview
  • High-impact, abuse-resistant nylon face
  • Spring termination greatly reduces the possibility of loosening the terminal connection with vibration and strand relaxation over time
  • Insulation barrier construction isolates ground contact from mounting strap
  • All-brass mounting and grounding system provides a lower resistance ground path and greater resistance to corrosion than steel mounting systems
