CIRCUIT BREAKER, POWERPACT H, 150A, 3 POLE, 600VAC, 18KA, I-LINE, THERMAL MAGNETIC, 80%, ABC

Manufacturer: Schneider | Square D | Catalog # HGA36150 | Electrozad South Part # 402918
*Call For Price*
Log in or register to view your price, purchase history, and more!
Usually ships within 12 to 18 days
Specification Sheet Product Brochure Installation / Instruction Manual CAD Drawing #1 CAD Drawing #2 CAD Drawing #3 G USERS MANUAL URL
PowerPacT H-Frame circuit breakers are designed to protect electrical systems from damage caused by overloads and short circuits. PowerPacT H-Frame circuit breakers are available with either thermal magnetic or Micrologic electronic trip protection units. This PowerPacT H-Frame circuit breaker provides thermal magnetic circuit protection with a breaking capacity of 18kA at 600VAC. All PowerPacT H-Frame circuit breakers are equipped with dual-break rotating contacts that reduce the amount of peak current during a short circuit fault. All PowerPacT circuit breakers have an integral push-to-trip button in the cover to manually trip the circuit breaker. PowerPacT H circuit breakers are available in 2 and 3-pole unit mount and I-Line constructions. PowerPacT H I-Line circuit breakers are available in I-Line construction for easy installation and removal in I-Line applications. This breaker has I-Line terminations on the line side and mechanical lugs on the load side. This PowerPacT H, 150A, 3 pole, circuit breaker has a breaking capacity of 18kA at 600VAC. This circuit breaker has a continuous current rating of 80% with an ABC phase connection. PowerPacT H circuit breakers comply to UL, CSA, NOM, and IEC standards and are CE marked.

Technical Information

Amperage
150 A
Applications
PROVIDES OVERLOAD AND SHORT CIRCUIT PROTECTION
Frame
H-FRAME
Interrupt Rating
20 kA at 500 V DC;65 kA at 240 V AC;35 kA at 480 V AC;18 kA 600 V AC;20 kA 250 V DC
Line Rated Current
150-150 A
Mounting Type
I-Line Bracket)
Net Weight
2.2 kg
Number of Phases
ABC
Number of Poles
3
Operating Temperature
-13F AND 158F (-25 C AND +70 C)
Standard
CSA,IEC 60947-2,NEMA,NOM-003-SCFI-2000,UL
Storage Temperature
-50-85 degrees C
Strip Length
16 mm
TC Connection
I-LINE CONNECTION (ON END) - LUGS (OFF END) ABC
Trip Point
1700-1700 A
Trip Range
HOLD: 900A - TRIP: 1700A
Trip Type
THERMAL-MAGNETIC
Type
circuit breaker
Voltage
250 V

Manufacturer Information

Brand
Square D
Sub Brand
POWERPACT

General Product Info

12-Digit UPC
785901795070
Color
Black
GTIN
00785901795070
Weight
2.2 kg

Dimensions

Depth
86 mm
Height
6.42 in
Length
16 mm
Warranty Length
18 mth
Width
4.09 in

Certifications & Compliance

Certifications
CSA,NOM,UL
Country of Origin
USA
