POWER RELAY, SE RELAYS, 15A, 4PDT, 120 VAC, CLEAR COVER

Manufacturer: Schneider Electric | Catalog # 784XDXC-120A | Electrozad South Part # 394027
*Call For Price*
Log in or register to view your price, purchase history, and more!
Usually ships within 12 to 18 days
Specification Sheet Product Brochure CAD Drawing #1 CAD Drawing #2 CAD Drawing #3
The SE Relays 784 series, plug-in general purpose relay offers robust and historically proven square base mounting relay platform that provides excellent structural support with clear cover. Contacts rated as 15A resistive at 277VAC, motor 1/2hp at 120VA

Technical Information

Contact Material
Silver Alloy, Gold Flashed
Dielectric Strength
1500 V
Input Voltage
120 V
Net Weight
71 g
Operating Temperature
-40-55 degrees C
Storage Temperature
-40-85 degrees C

Manufacturer Information

Brand
Schneider Electric

General Product Info

12-Digit UPC
606480281238
GTIN
03606480281235
Weight
71 g

Dimensions

Depth
1.07 in
Height
1.37 in
Width
1.6 in

Certifications & Compliance

Certifications
CE,CSA,UL
Country of Origin
China
