SAFETY SWITCH, HEAVY DUTY, FUSIBLE, 30A, 3 POLE, 20HP, 600VAC/600VDC, NEMA 4, 4X, 5, 316 STAINLESS STEEL

Manufacturer: Schneider | Square D | Catalog # H361SS | Electrozad South Part # 379841
*Call For Price*
Log in or register to view your price, purchase history, and more!
Usually ships within 12 to 18 days
Specification Sheet Product Brochure Installation / Instruction Manual CAD Drawing #1 CAD Drawing #2 CAD Drawing #3
These Square D heavy duty safety switches are designed to provide exceptional electrical protection in the most grueling conditions. They have been designed to have a significantly higher durability than a standard switch and have a durability three time

Technical Information

Applications
HEAVY DUTY SAFETY SWITCHES ARE DESIGNED FOR THE FOLLOWING APPLICATIONS UP TO 600VAC OR 600VDC 30-1200 AMPERES, 200,000 RMS SYMMETRICAL AMPERES SHORT CIRCUIT CURRENT.
Contact Configuration
3
Contact Rating
Y
Current
30 A
Disconnect Type
Fusible disconnect
Duty Rating
Heavy duty
Enclosure
4,4X,5
Enclosure Material
Stainless Steel
Enclosure Rating
NEMA 4/4X/5 stainless steel 316
Fuse Type
H Or K,R Or J
Line Rated Current
30 A
Mounting Type
Surface
Net Weight
6 kg
Number of Phases
3
Number of Poles
3
Short Circuit Current
10 kA
Size
14.93 IN,5.11 IN,8.67 IN
TC Connection
AWG 12...AWG 6 ALUMINIUM-AWG 14...AWG 6 COPPER,LUGS
Type
SAFETY SWITCH
Voltage
600 V
Wattage
4, 4X, 5
Wire Size
AWG 12...AWG 6 aluminium;AWG 14...AWG 6 copper

Manufacturer Information

Brand
Square D
Sub Brand
HEAVY DUTY

General Product Info

12-Digit UPC
785901695578
Environmental Conditions
RAINPROOF, DUST TIGHT AND CORROSION RESISTANT (INDOOR/OUTDOOR)
Weight
13.23 lb

Dimensions

Depth
5.11 in
Height
14.93 in
Warranty Length
18 mth
Width
8.67 in

Certifications & Compliance

Certifications
UL Listed File E2875
Country of Origin
USA
