Receptacle straight 2P3W 125V 20A orange

Manufacturer: Leviton Manufacturing | Catalog # 8300-OIG | Electrozad South Part # 378971
*Call For Price*
Log in or register to view your price, purchase history, and more!
Usually ships within 12 to 18 days
Specification Sheet MDM SAFETY DATA SHEET Product Brochure Product Catalog Page MSDS | SDS Safety Sheet
Leviton hospital grade receptacle undergo the most stringent UL testing to assure continuous, safe operation in any application requiring high-abuse tolerance, including health care facilities, manufacturing plants and schools. Isolated Ground, Back and side wired, Nickel plated brass strap.

Technical Information

Amperage
20 A
Applications
Hospital
Body Material
PBT,PBT,Polyester Blend,Polyester Blend
Conductor Size
14-10 AWG
Connection Type
Back And Side Wired
Device Type
Duplex Receptacle Outlet
Dielectric
3000 V
Dielectric Strength
2000 V
Face Material
PBT,PBT,Polyester Blend,Polyester Blend
Flamability Class
Rated V-0 Per UL 94,Rated V-0 Per UL 94
Grade
Heavy Duty Hospital
Grounding
Self-Grounding
Horsepower
1 hp
Material
Thermoplastic, Polyester Face
Mounting Type
Wall Box
NEMA
5-20R
Number of Phases
1
Number of Poles
2
Number of Wires
3
Operating Temperature
60 degrees C
Size
46 H x 1.53 W x 1.11 D IN
Standard
ANSI C-73
TC Connection
Back and Side Wired
Temperature Rating
-40 degrees C to 60 degrees C
Temperature Rise
30 degrees C
Termination Type
Back Wire,Side Wire
Type
Straight Blade
Voltage
125 V
Wattage
1 hp
Wire Count
3,3
Wire Size
14 - 10 AWG
Wire Type
Stranded Building Wire

Manufacturer Information

Brand
Leviton
Sub Brand
Industrial Receptacles

General Product Info

12-Digit UPC
078477057384
Color
Orange
Environmental Conditions
UL 94 V-0 Flammability
GTIN
00078477057384

Dimensions

Warranty Length
10 yr

Certifications & Compliance

Certifications
CULus,NOM-ANCE
Country of Origin
Mexico
