..LFLEX® VFD 2XL W/SIGNAL 14/4C+18/2C

Manufacturer: Olflex Wire Cables | Catalog # 700711 | Electrozad South Part # 370837
*Call For Price*
Log in or register to view your price, purchase history, and more!
Usually ships within 12 to 18 days
Specification Sheet Product Catalog Page
Servo cable; 4G2,5+(2x1); U.../U: 0,6 / 1 kV; TPE; Shielded; UL listed; Flexible

Technical Information

Applications
For Connecting Cable Between Frequency Converter and Motor, Fixed Installation or Applications with Occasional Movements, Plant Engineering, Industrial Machinery and Machine Tools
Conductor Material
Tinned Copper
Conductor Size
14 AWG, 18 AWG (Signal)
Insulation Material
XLPE
Number of Conductors
4, 1 Shielded Pair (Signal)
Shield Type
Tape/Braided
Temperature Rating
-25 to 90 degrees C
Type
Multi-Listed, Flexible

Manufacturer Information

Brand
Lapp
Sub Brand
Olflex VFD 2XL

General Product Info

Jacket Color
Black
Jacket Material
Thermoplastic Elastomer
Weight
375 kg/km

Dimensions

Length
305 m
Outside Diameter
17.4 mm
