Tamper-Resistant Single Receptacle, 15 Amp 250 Volt, White

Manufacturer: Leviton Manufacturing | Catalog # T5661-W | Electrozad South Part # 366788
*Call For Price*
Log in or register to view your price, purchase history, and more!
Usually ships within 12 to 18 days
Specification Sheet MDM SAFETY DATA SHEET Product Brochure Product Catalog Page Installation / Instruction Manual MSDS | SDS Safety Sheet
Single Receptacle Outlet, Heavy-Duty Industrial Specification Grade,  Tamper-Resistant, Smooth Face, 15 Amp, 250 Volt, Back and Side Wire, NEMA 6-15R, 2-Pole, 3-Wire, Self-Grounding - White

Technical Information

Amperage
15 A
Body Material
Nylon
Device Type
Single Receptacle Outlet
Dielectric
2000 V
Face Material
PBT
Flamability Class
Rated V-2 Per UL 94
Grade
Heavy-Duty Industrial Specification
Grounding
Self-Grounding
Horsepower
1-1/2 hp
NEMA
6-15R,WD-1,WD-6
Number of Poles
2
Operating Temperature
-40 degrees C
Temperature Rise
30 degrees C
Wire Count
3

Manufacturer Information

Brand
Leviton
Sub Brand
TAMPER RESISTANT COMMERCIAL RECEPTA

General Product Info

12-Digit UPC
078477066393
Color
White
GTIN
00078477066393

Dimensions

Warranty Length
10 yr

Certifications & Compliance

Certifications
CSA C22.2, No. 42,Fed Spec WC-596,NOM,UL 498
Country of Origin
Mexico
