ETHERLINE® FD P CAT.6 4X2XAWG26

Manufacturer: Olflex Wire Cables | Catalog # 2170488 | Electrozad South Part # 332849
*Call For Price*
Log in or register to view your price, purchase history, and more!
Usually ships within 12 to 18 days
Specification Sheet Product Catalog Page
Ethernet cable; Cable chain, Flexible; EtherCAT, ETHERNET/IP; Cat.6; SF/UTP; PUR; Halogen-free; green

Technical Information

Applications
Drag Chains and Moving Machinery Parts in Dry or Damp Rooms, Plant Engineering, Machinery Manufacturing, EtherCAT and EtherNet/IP Applications
Bend Radius
31.2 mm
Conductor Material
Copper
Impedance
100
Insulation Material
Polypropylene
Number of Conductors
4 Pair
Operating Temperature
-30 degrees C
Stranding
Stranded Wire
Temperature Rating
-40 to 80 degrees C
Type
Industrial
Voltage
48 V

Manufacturer Information

Brand
Lapp
Sub Brand
Etherline®

General Product Info

Insulation Color
Green
Jacket Color
Green
Jacket Material
Thermoplastic Copolymer Inner, PUR Outer
Weight
63 kg/km

Dimensions

Outside Diameter
7.8 mm
