ETHERLINE® FD P CAT.6A 4X2X24/7AWG

Manufacturer: Olflex Wire Cables | Catalog # 2170484 | Electrozad South Part # 331546
*Call For Price*
Log in or register to view your price, purchase history, and more!
Usually ships within 12 to 18 days
Specification Sheet Product Catalog Page
Ethernet cable; Cable chain, Flexible; ETHERNET/IP, PROFINET; PROFINET® application: Type C; Cat.6A; SF/UTP; PUR; Halogen-free; green

Technical Information

Applications
For High Flexible use in Drag Chain
Bend Radius
15 X Cable Diameter
Conductor Material
Bare Copper
Insulation Material
FEP
Number of Conductors
2 Pair
Operating Temperature
-10 degrees C
Shield Type
Foil and Braid
Stranding
Stranded Wire
Temperature Rating
-40 to 80 degrees C
Type
Halogen Free
Voltage
48 V

Manufacturer Information

Brand
Lapp
Sub Brand
Etherline®

General Product Info

Jacket Color
Green
Jacket Material
Polyurethane
Weight
90 kg/km

Dimensions

Length
100 m
Outside Diameter
8.9 mm
