CONTACTOR, IEC, TESYS K, 9A, 3 P, 5 HP AT 480VAC, NONREVERSING, 1 NO AUXILLIARY CONTACT, 110VAC 50/60 HZ COIL

Manufacturer: Telemecanique Controls | Catalog # LC1-K0910F7 | Electrozad South Part # 320899

*Call For Price*
Log in or register to view your price, purchase history, and more!
Usually ships within 12 to 18 days
TeSys K contactors have been designed for perfect integration into control systems. They can be used to create motor starters for any type of application. They can be used to create motor starters for almost any type of application. TeSys K contactors offer quick simple setup, while maintaining a compact size. Contactors have both Horsepower and Kw motor rating for international acceptance. An extennsive line of accessories makes it easy to meet the requirements of most applications. These contactors are UL Listed and CSA certified. Multi standards certified (IEC, UL, CSA, CCC, EAC).

Technical Information

Applications
CONTROL,RESISTIVE LOAD-MOTOR CONTROL
Coil Voltage
110@50/60Hz VAC
Contact Configuration
1 NO,3 NO
Contact Rating
20 A 50 A°C POWER CIRCUIT-10 A 50 A°C SIGNALLING CIRCUIT
Impedance
3 MOhm - Ith 20 A 50 Hz For Power Circuit
Operating Cycles
3600 cyc/h
Range
TeSys
Size
3P
Standard
CSA C22.2 No 60947-4-1,EN/IEC 60947-4-1,GB/T 14048.4,JIS C8201-4-1,UL 60947-4-1
Type
Contactor

Manufacturer Information

Brand
Schneider Electric
Sub Brand
TESYS K

General Product Info

12-Digit UPC
785901883173
GTIN
03389110428483

Dimensions

Depth
57 mm
Height
2.28 in
Warranty Length
18 mth
Width
1.77 in

Certifications & Compliance

Certifications
CB Scheme,CCC,CE,CSA,EAC,UKCA,UL
Country of Origin
Indonesia
