Switch DECORA PLUS rocker 1-pole thermoplastic 20A 120/277V white

Manufacturer: Leviton Manufacturing | Catalog # A5621-2W | Electrozad South Part # 314070
*Call For Price*
Log in or register to view your price, purchase history, and more!
Usually ships within 12 to 18 days
Specification Sheet MDM SAFETY DATA SHEET Product Brochure MSDS | SDS Safety Sheet
decora plus™ Antimicrobial treated switch is made with antimicrobial additives to reduce the growth of harmful bacteria on their surfaces. Antimicrobial treated devices is certified by NSF International to meet sanitation requirements for use in food handling and processing environments. Rocker material embedded with silver ion antimicrobial additive.

Technical Information

Actuator
Rocker/Button
Amperage
20 A
Body Material
Thermoplastic Polyester
Contact Material
Silver-Alloy
Device Type
Rocker Switch
Dielectric
1500 V
Enclosure
WD-6
Flamability Class
Rated HB Or Better UL94
Grade
Commercial Specification
Grounding
Self-Grounding
Horsepower
1 hp
Material
Thermoplastic
NEMA
WD-1
Number of Poles
1
Operating Temperature
-40 degrees C
Storage Temperature
-40 degrees C
Temperature Rise
30 degrees C
Terminal Type
Screw
Termination Type
Back Wire,Side Wire
Torque
12 lb-in
Type
Switch
Voltage
120/277 V

Manufacturer Information

Brand
Leviton
Sub Brand
Decora Plus™

General Product Info

12-Digit UPC
078477727362
Color
White
Finish
Matt
GTIN
00078477727362

Dimensions

Warranty Length
10 yr

Certifications & Compliance

Country of Origin
Mexico
CSA
C22.2
