Sensor occupancy 360.. 277V 1200VA white 2000sqft

Manufacturer: Leviton Manufacturing | Catalog # ODC20-MDW | Electrozad South Part # 313794

*Call For Price*
Log in or register to view your price, purchase history, and more!
Usually ships within 12 to 18 days
The Leviton Provolt™ series combine line voltage occupancy sensors and photocells into a self-contained unit. The integrated design alleviates the need for separate power pack and occupancy sensor wiring making it a low-cost, efficient energy solution for new construction and retrofits. For true Daylight Harvesting applications, integrated photocells provide consistent Daylight Design Levels by actively switching the connected load(s) ON and OFF in response to available natural light to maximize energy savings. Vacancy timers continually analyze and adjust to changing conditions using the latest microprocessor-based technology to optimize performance. Auto ON/Auto OFF automatically turns lights ON and keeps them ON when occupancy is detected and automatically turns lights OFF when the space is vacant or unoccupied. Wire terminals allow for simple connection to a line-voltage circuit and are ideal for existing buildings with limited access to wiring and new construction.

Technical Information

Applications
For Commercial Use
Coverage
2000 sq-ft
Frequency
50/60 Hz
Grade
Commercial
Material
Plastic
Mounting Type
Surface/Ceiling
Operating Temperature
0 degrees
Response Time
30 min
Sensor Type
Passive Infrared, Ultrasonic
Size
2.39 in
Standard
CA Title 20 Complaint,NEMA 410,NOM Certified,NY LLC48 Complaint,RoHS Complaint,UL (773A),UL 924
Temperature Rating
0 degrees C to 40 degrees C
Type
Adjustable
Voltage
120 To 277 V

Manufacturer Information

Brand
Leviton
Sub Brand
C/I OCCUPANCY SENSORS

General Product Info

12-Digit UPC
078477540022
Color
White
Environmental Conditions
Relative Humidity (0 To 90 PCT),Storage Temperature (-26 DEG C To +71 DEG C)
GTIN
40078477540020

Dimensions

Warranty Length
5 yr

Certifications & Compliance

Country of Origin
China
