PLUG ANG, 60A 125/250V, 14-60P

Manufacturer: Bryant Wiring Device | Catalog # 9462ANPB | Electrozad South Part # 303828
*Call For Price*
Log in or register to view your price, purchase history, and more!
Usually ships within 12 to 18 days
Specification Sheet
Straight Blade Devices, Male Plug, Heavy Duty, Industrial/Commercial Grade, Angled, 60A 125/250V, 3-Pole 4-Wire Grounding, 14-60P, Black, Single Pack

Technical Information

Amperage
60 A
Applications
Heavy Duty
Cord Type
All Portable
Current
60 A
Material
Composite
NEMA
14-60R
Number of Phases
1
Number of Poles
3,3
Number of Wires
4,4
Size
Standard Sized
Style
Heavy Duty
TC Connection
Pressure Terminal Screws
Type
Standard
Voltage
125/250 V
Wattage
15000 W
Wire Size
6-4 AWG

Manufacturer Information

Brand
Hubbell
Sub Brand
Bryant

General Product Info

12-Digit UPC
781786676626
Color
Black
GTIN
00781786676626
Product Series
Industrial
Product UPC
78178667662
Weight
0.95 lb

Dimensions

Height
4.048 in
Length
4.048 in
Width
3.5 in

Certifications & Compliance

Country of Origin
USA
Overview
  • 3-Pole 4-Wire Grounding
  • Angled
  • Industrial/Commercial Grade
  • Heavy Duty
  • 60A 125/250V
