CR-M024DC2L PLUGGABLE INTERFACE REL

Manufacturer: ABB Inc | Catalog # 1SVR405611R1100 | Electrozad South Part # 303755
*Call For Price*
Log in or register to view your price, purchase history, and more!
Usually ships within 12 to 18 days
Specification Sheet Product Brochure
Plugin control relay with 24 VDC rated control supply voltage, SPDT (2 c/o) contacts, contacts, with LED indicator and 250 V, 12 A contact rating

Technical Information

Applications
For Electrical Isolation, Amplification and Signal Matching Between the Electronic Controlling
Contact Configuration
SPDT - 2 CO
Contact Material
Silver Nickel
Mounting Type
8 Blade Socket
Number of Poles
1
Operating Cycles
20000000
Power Rating
0.9 W
Resistance
640
Size
21.2x35.6x27.5
Temperature Rating
-40 to 70 degrees C
Type
Miniature

Manufacturer Information

Brand
ABB
Sub Brand
CR-M

General Product Info

12-Digit UPC
662019362649
GTIN
04013614497230
