LKG CONN, 20A 250V, L6-20R, B/W

Manufacturer: Bryant Wiring Device | Catalog # 70620NC | Electrozad South Part # 295384
*Call For Price*
Log in or register to view your price, purchase history, and more!
2 available

For Delivery

Not in local stock *
Check another branch
Specification Sheet
Locking Devices, Industrial, Female Nylon Connector Body, 20A 250V, 2-Pole 3-Wire Grounding, L6-20R, Screw Terminal, Black/White

Technical Information

Amperage
20 A
Applications
Heavy Duty Industrial
Current
20 A
Material
Composite
NEMA
L6-20R
Number of Conductors
3-Wire Grounding
Number of Poles
2,2
Number of Wires
3
Size
Standard Sized Product
Style
Internal Cord Clamp
TC Connection
Screw Terminals
Temperature Rating
-40 degrees C
Type
Tech-Spec Triple Gripper
Voltage
250 V
Wire Size
18-8 AWG

Manufacturer Information

Brand
Hubbell
Sub Brand
Bryant

General Product Info

12-Digit UPC
781786689299
Color
Black,White
GTIN
00781786689299
Product UPC
78178668929

Dimensions

Height
3.90 in
Length
2.13 in
Width
2.0 in

Certifications & Compliance

Country of Origin
China
Overview
  • Impact/chemical resistant, toughened nylon construction
  • Amperage, voltage and NEMA configuration imprinted on face for easy identification
  • Face and body feature alignment keys for easy assembly
  • Internal self-centering Triple Gripper® cord grip with radius teeth design provides secure cord retention
