LKG SGL RCPT, 15A 125V, L5-15R

Manufacturer: Bryant Wiring Device | Catalog # 4710 | Electrozad South Part # 295378
*Call For Price*
Log in or register to view your price, purchase history, and more!
1 available

For Delivery

Not in local stock *
Check another branch
Specification Sheet
Locking Devices, Industrial, Flush Receptacle, 15A 125V, 2-Pole 3-Wire Grounding, L5-15R, Screw Terminal, Black

Technical Information

Amperage
15 A
Applications
Extra Heavy Duty Industrial Specification Grade
Current
15 A
Material
Composite
NEMA
L5-15R
Number of Phases
1
Number of Poles
2
Number of Wires
3
Size
Standard Sized Product
Style
Single Receptacle
TC Connection
Terminal Screws
Type
Single
Voltage
125 V
Wattage
1875 W
Wire Size
14-8 AWG

Manufacturer Information

Brand
Hubbell
Sub Brand
Bryant

General Product Info

12-Digit UPC
781786174016
Color
Black
GTIN
00781786174016
Product UPC
78178617401

Dimensions

Height
1.01 in
Length
3.28 in
Width
1.41 in
Overview
  • All terminals are back and side wired
  • Single piece, all brass contacts
  • Reinforced thermoplastic construction
  • Brass mounting strap with stainless steel grounding clip
