Ceiling sensor Ultrasonic 1000 sq. ft. w/relay/photocell

Manufacturer: Hubbell Wiring Devices | Catalog # OMNIUS1000RP | Electrozad South Part # 292991

*Call For Price*
Log in or register to view your price, purchase history, and more!
Usually ships within 12 to 18 days
The OMNIUS uses ultrasonic (US) technology to turn lighting on and off based on occupancy. Designed specifically for both areas with obstructions (e.g. columns, cubicles, stalls, and filing cabinets) and areas with long periods of minor-motion activity (e.g. typing), this sensor features Hubbell Controls' patented IntelliDAPT® technology, which makes all the sensor adjustments automatically. IntelliDAPT self-adaptive technology - no manual adjustment required. Superior all-digital ultrasonic (US) minor motion detection. Non-volatile memory for sensor settings. 500...2,000 square-foot coverage area (depending on model). Optional relay and photocell control. Optional Quick to Install (QTI) connector. UL and cUL listed. California Title 24 compliant. Low Voltage 24 Vdc.

Technical Information

Amperage
33 mA
Applications
For Commercial Indoor, Education, Healthcare, Hospitality, Manufacturing, Retail, Warehouse
Lens Type
LED
Material
High Impact Injection Molded Plastic
Mounting Type
Surface/Ceiling
Operating Temperature
32 to 104 degrees F
Response Time
8 - 30 min (Auto Mode), 8 sec (Test Mode)
Temperature Rating
32 - 104 degrees F
Type
Low Voltage

Manufacturer Information

Brand
Hubbell
Sub Brand
Omni®

General Product Info

12-Digit UPC
640181403117
Color
Off-White
Environmental Conditions
Indoor
GTIN
00640181403117
Product UPC
64018140311

Dimensions

Height
6.300 in
Length
5.400 in
Warranty Length
5 yr
Width
2.400 in

Certifications & Compliance

Country of Origin
China
