Protector FIRSTSURGE PRO surge 140000A

Manufacturer: Siemens Distribution | Catalog # FS140 | Electrozad South Part # 286091
*Call For Price*
Log in or register to view your price, purchase history, and more!
Usually ships within 12 to 18 days
Specification Sheet Product Brochure Product Catalog Page Wiring Diagram
FirstSurge™ Pro home surge protector with beep audible alarm, extinguished green LED and flashing red service light. FirstSurge™ is GRM-equipped notifying you a rare safety hazard exists due to a compromised electrical system neutral to ground bond. 3 stage commercial grade notification. Type 4 rated outdoor enclosure.

Technical Information

Applications
For Residential use
Connection Type
Wired
Nominal Discharge Current
140 kA
Number of Phases
1
Operating Temperature
-40degrees C (-40degrees F) to +60degrees C (+140degrees F)
Response Time
1 Nanosecond
Size
8Lx4Hx3W
TC Connection
Wired
Temperature Rating
-40 degrees C to 60 degrees C
Terminal Type
Wired
Voltage
120 V

Manufacturer Information

Brand
Siemens
Sub Brand
FirstSurge™ Pro

General Product Info

12-Digit UPC
804766055560
GTIN
00804766055560
Weight
3.000 lb

Dimensions

Height
4.450 in
Length
9.700 in
Width
5.900 in

Certifications & Compliance

Country of Origin
USA
