Box assembly floor duplex receptacle 2P 3W 125V 15AMP brass/ivory

Manufacturer: Leviton Manufacturing | Catalog # 25249-TFB | Electrozad South Part # 276045
*Call For Price*
Log in or register to view your price, purchase history, and more!
Usually ships within 12 to 18 days
Specification Sheet MDM SAFETY DATA SHEET Product Brochure Installation / Instruction Manual MSDS | SDS Safety Sheet Technical Drawing
Leviton's line of heavy-duty specification grade receptacles are designed and manufactured to withstand the most demanding environments. Available in a wide variety of configurations, including isolated ground, tamper-resistant, etc., these commercial grade devices are the electrical contractor's choice for use in hotels, schools, hospitals and commercial office buildings.

Technical Information

Amperage
15 A
Applications
Commercial
Body Material
Nylon
Dielectric
2000 V
Dielectric Strength
2000 (Min.)
Enclosure
WD-6
Face Material
Nylon
Flamability Class
Rated V-2 Per UL 94
Grounding
Self-Grounding
Horsepower
1/2 hp
Material
Nylon
Mounting Type
Floor Box
NEMA
WD-1
Number of Poles
2
Number of Wires
3
Operating Temperature
-40 degrees C
Size
4.50 H x 3.75 W x 4.50 D IN
Standard
ANSI C-73
Temperature Rating
-40 To 60 degrees C
Temperature Rise
150 %
Termination Type
Back Wire,Side Wire
Type
Floor Box Duplex Receptacle
Voltage
125 V
Wire Count
3
Wire Size
14-10 AWG

Manufacturer Information

Brand
Leviton
Sub Brand
FLOOR BOXES and POKE THROUGHS

General Product Info

12-Digit UPC
078477411520
Color
Ivory
Environmental Conditions
Flammability (Rated V-2 Per UL94)
GTIN
00078477411520

Dimensions

Warranty Length
10 yr

Certifications & Compliance

Country of Origin
Mexico
