Fan ventilation 0.3A 80CFM

Manufacturer: Broan | Catalog # LP80 | Electrozad South Part # 267265

*Call For Price*
Log in or register to view your price, purchase history, and more!
Usually ships within 12 to 18 days
Plug-in, permanently lubricated motor-engineered for continuous operation. Dynamically balanced centrifugal blower wheel for quiet, efficient performance. Low RPM for quiet operation. Rugged, galvanized steel construction. Metal, 4 inch oval duct connector with no metallic clatter. Includes 4 inch oval to 3 inch round duct reducer. 4 inch height allows for 2 x 4 wall or ceiling installation. Sturdy, easy, mounting directly to stud or joist. Can be mounted in flat ceilings, sloped ceilings up to 12/12 pitch and walls. Polymeric construction. Innovative design-the result of extensive research with designers and consumers. UL listed for use over bathtubs and showers when connected to a GFCI protected branch circuit.

Technical Information

Airflow Rate
80 CFM
Amperage
0.3 A
Duct Shape
Oval
Duct Size
3 in
Motor Type
Permanent Split Capacitor
Mounting Type
Ceiling
Nightlight
No
Power Rating
25.7 W
Type
Low Profile
Voltage
120 V
Wattage
25.7 W

Manufacturer Information

Brand
Broan-Nutone

General Product Info

12-Digit UPC
026715203475
Color
White
Grille Material
Polymeric
GTIN
00026715203475
Housing Material
Galvanized Steel
Weight
9 lb

Dimensions

Grille Length
13 in
Grille Width
13-3/4 in
Height
4 in
Housing Length
10-1/2 in
Housing Weight
4 in
Housing Width
11-3/8 in
Length
10.5 in
Warranty Length
1 yr
Width
13.75 in

Certifications & Compliance

Country of Origin
China
