Tab male terminal full insul.25T-12/10ga yellow

Manufacturer: ABB | Thomas & Betts | Catalog # 10RC-2577 | Electrozad South Part # 267049
*Call For Price*
Log in or register to view your price, purchase history, and more!
Usually ships within 12 to 18 days
Specification Sheet Product Brochure Product Catalog Page
The T B Sta-Kon series is designed to provide solutions to single cabling to terminal strip, they are available in many forms (fork, pin, tab, ring), colors matching ranges of wire gage, insulated or not. Made of copper lugs with plastic nylon insulated. Crimpable with tools provided. CSA approved.

Technical Information

Conductor Size
10-12 AWG
Insulation Material
Nylon
Insulation Type
Nylon,Polyamide
Material
Brass
Standard
CSA,E2186,UL
Temperature Rating
105 degrees C
Type
Long Sleeve
Voltage
600 V

Manufacturer Information

Brand
ABB
Sub Brand
Sta-Kon®

General Product Info

12-Digit UPC
786210839318
Color
Yellow
Finish
Electro-Tin Plated
GTIN
05414363935735
Used With
Round Conductors
