3P SW 100A J FUSE 600V UL98

Manufacturer: ABB Inc | Catalog # OS100GJ12 | Electrozad South Part # 264973
*Call For Price*
Log in or register to view your price, purchase history, and more!
Usually ships within 12 to 18 days
Specification Sheet
3 pole 100 amperes rated at 600 VAC open fusible disconnect switch for use with J fuse type. 147 millimiters width x 172 millimiters height x 105 millimiters depth. Front operated. Include terminal bolt kit (M8x25).

Technical Information

Amperage
100 A
Applications
For Use as Motor Disconnects or Industrial Control Panel Disconnects on Service Entrance Equipment, Panelboards, Switchboards, Industrial Control Equipment, Motor Control Centers
Connection Type
Lug Terminal
Contact Configuration
1 NO, 1 NC
Fuse Type
Class J
Interrupt Rating
200 kA
Load Rating
75 hp
Mounting Type
Base
Number of Poles
3
Temperature Rating
40 degrees C
Type
Open, Front Operated, Fusible
Voltage
600 V

Manufacturer Information

Brand
ABB

General Product Info

12-Digit UPC
804325571562
GTIN
00804325571562
