Plug safety shroud twist-lock 3-pole 4-wire 3HP NEMA L15-30P 30A 250V

Manufacturer: Hubbell Wiring Devices | Catalog # HBL2721S | Electrozad South Part # 22775
*Call For Price*
Log in or register to view your price, purchase history, and more!
Usually ships within 12 to 18 days
Specification Sheet Product Catalog Page Installation / Instruction Manual Technical Drawing Manufacturer Warranty
Twist-Lock® Safety-Shroud® Plug, ribbed nylon housing provides a secure grip and impact and chemical resistance. Superior cord grip design protects terminations from excess strain. Integral dust shield protects wiring chamber from dust or contaminants. Black and white nylon body, white Valox® shroud. Can be used with the insulgrip connector bodies.

Technical Information

Amperage
30 A
Applications
Power Connection
Conductor Size
10-8 AWG
Cord Type
Portable
Current
30 A
Horsepower
3 hp
Material
Composite
Mounting Type
Cord
NEMA
L15-30P
Number of Phases
3
Number of Poles
3
Number of Wires
4
Operating Temperature
-40 degrees C
Size
2.33 in x 2.33 in x 4.21 in
Standard
CSA C22.2 No.42,Fed.Spec. W-C-596,UL 498
TC Connection
Terminal Screws
Type
Male, Shrouded
Voltage
250 V
Wattage
7500 W
Wire Count
4
Wire Size
16-8 AWG

Manufacturer Information

Brand
Hubbell Wiring Device Kellems
Sub Brand
Twist-Lock®

General Product Info

12-Digit UPC
783585234786
Color
Black,White
Environmental Conditions
Indoor Dry Unless Protected By Additional Means
GTIN
00783585234786
Product UPC
78358523478
Weight
0.45 lb

Dimensions

Height
4.21 in
Length
2.33 in
Width
2.33 in

Certifications & Compliance

Country of Origin
USA
Overview
  • Integral dust shield protects wiring chamber from dust or contaminants
  • Superior cord grip design protects terminations from excess strain.
  • Ribbed nylon housing provides a secure grip and impact and chemical resistance.
