Receptacle straight duplex 2P 2W 125V 15AMP yellow

Manufacturer: Leviton Manufacturing | Catalog # 80W04-D | Electrozad South Part # 221906
*Call For Price*
Log in or register to view your price, purchase history, and more!
Usually ships within 12 to 18 days
Specification Sheet MDM SAFETY DATA SHEET Product Brochure Installation / Instruction Manual MSDS | SDS Safety Sheet
Straight blade duplex outlet. Industrial grade, non-grounding.

Technical Information

Amperage
15 A
Applications
For General and Industrial ID, Indoor/Outdoor Use
Device Type
Straight Blade Outlet
Dielectric
2000 V
Flamability Class
Rated V-2 Per UL 94
IP Rating
IP66
NEMA
WD-6
Number of Poles
2
Number of Wires
2
Operating Temperature
60 degrees C
Standard
ANSI C-73
Temperature Rise
200 %
Type
Duplex Outlet
Wire Count
2

Manufacturer Information

Brand
Leviton
Sub Brand
Wetguard®

General Product Info

12-Digit UPC
078477518434
Color
Yellow
Environment
Wet
GTIN
00078477518434

Dimensions

Warranty Length
Lifetime Limited

Certifications & Compliance

Country of Origin
Mexico
CSA
C22.2 No. 42
