Connector locking 4P 5W 347/600V 20AMP yellow

Manufacturer: Leviton Manufacturing | Catalog # 27W83 | Electrozad South Part # 221769

*Call For Price*
Log in or register to view your price, purchase history, and more!
Usually ships within 12 to 18 days
Corrosion-resistant electroless nickel-coated brass blades, contacts, terminal screws and wiring clamps and stainless steel assembly screws make these devices ideal for use in wet and corrosive environments. EPTR rubber part provides outstanding resistance to wet and damp environments, extreme temperature variations, water, acids, alkalis, grease, oils and many automotive and industrial lubricants and solvents. Plug and connector husk is molded to a bondable nylon body, providing a device that withstands physical abuse. Interlocking tongue and groove construction seals out water, moisture and dirt when plugs are mated with connectors. Multi-point sealing system utilizes nut, strain relief washer and rubber bushing to form a watertight cord grip seal. Non-magnetic stainless steel fast-threading assembly screws won't interfere with sensitive equipment. Connector hood closure cap seals device when not in use.

Technical Information

Actuator
Stainless Steel 300
Amperage
20 A
Applications
Industrial
Blade Type
Nickel-Plated Brass
Body Material
EPTR Rubber
Connection Type
Screw Terminal
Contact Material
Nickel-Plated Brass
Cord Type
SO,SOO,ST,STO
Device Type
Locking Connector
Grounding
Grounding
Material
TPV
Mounting Type
Cable
NEMA
L22-20R
Number of Phases
3
Number of Poles
4
Number of Wires
5
Screw Type
Stainless Steel 300
Size
2.50 Diameter X 5.52 L IN
Standard
CSA,UL
TC Connection
Screw Terminal
Type
Locking,Watertight Connector
Voltage
347/600 V
Wire Count
5
Wire Size
18-10 AWG

Manufacturer Information

Brand
Leviton
Sub Brand
DUSTGUARD WETGUARD

General Product Info

12-Digit UPC
078477967942
Color
Yellow
Environment
Wet
Environmental Conditions
Operating Temperature Range (-40 To 60) °C
GTIN
00078477967942

Dimensions

Warranty Length
Lifetime Limited

Certifications & Compliance

Country of Origin
Mexico
