DSD COVER DEVICE SUB-ASSEMBLY 2 CIR UNIV

Manufacturer: Crouse Hinds | Catalog # DSD923 | Electrozad South Part # 219551
*Call For Price*
Log in or register to view your price, purchase history, and more!
Usually ships within 12 to 18 days
Specification Sheet Product Brochure Installation / Instruction Manual
Eaton Crouse-Hinds series DSD selector switch cover and device sub-assembly, 10A, Feraloy iron alloy, 2 position, 2 circuit, Factory sealed, Maintained contact, 600 Vac

Technical Information

Action
Maintained
Amperage
10 A
Applications
EDSCM Modular Control Device Bodies and EDS/EDSC Back Boxes
Contact Rating
600 VAC at 10 A
Enclosure
Class I Div 1 2 Group B C D,Class II Div 1 Group E F G,Class II Div 2 Group F G,Class III,NEMA 3/7B/7C/7D/9E/9F/9G
Enclosure Type
NEMA 3, 7B, 7C, 7D, 9E, 9F, 9G
Material
Feraloy Iron Alloy
Type
2-Circuit, 2-Position, Factory Sealed, Heavy-Duty
Voltage
600 V

Manufacturer Information

Brand
Crouse-Hinds

General Product Info

12-Digit UPC
782274235325
GTIN
00782274235325
Used With
EDSCM Modular Control Device Bodies and EDS/EDSC Back Boxes
Weight
3.75 lb

Dimensions

Height
4.6 in
Length
5.2 in
Width
6.8 in
