THQL 2POLE 120/240V 10K IC 40 AMPS

Manufacturer: General Electric | Catalog # THQL2140 | Electrozad South Part # 205206
*Call For Price*
Log in or register to view your price, purchase history, and more!
Usually ships within 12 to 18 days
Specification Sheet
THQL 2POLE 120/240V 10K IC 40 AMP

Technical Information

Amperage
40 A
Applications
Electrical distribution and Control
Frame
Q-Line
Interrupt Rating
10kA@120 Vac / 10kA@120/240 Vac
Load Rating
HACR
Number of Poles
2
Standard
Yes
Trip Range
Non-Interchangeable
Trip Type
LI
Type
Circuit Breakers
Voltage
240 V

Manufacturer Information

Brand
Emerson
Sub Brand
GE Industrial Solution

General Product Info

12-Digit UPC
783164012934
GTIN
00783164012934
