Panel FSP adapter unloaded 4port 16x14x3.25in

Manufacturer: Hubbell Wiring Devices | Catalog # FCW4SP | Electrozad South Part # 133689
*Call For Price*
Log in or register to view your price, purchase history, and more!
Usually ships within 12 to 18 days
Specification Sheet Product Catalog Page Technical Drawing
OPTICHANNEL™ double-door cabinet accept FSP series adapter panels and splice trays. Made of cold rolled steel and durable black powder coat. Separate, lockable user and installer-side tamper-resistant compartments. Designed for applications that require interconnections, cable management and routing of fiber in a secure environment.

Technical Information

Applications
FCW Wall Mount Cabinet, Double Door
Cable Entry
Top/Bottom
Gauge
16 ga
Material
Cold Rolled Steel
Mounting Type
Wall, Stud
Type
Double Door

Manufacturer Information

Brand
Hubbell
Sub Brand
OptiChannel™

General Product Info

12-Digit UPC
662620804996
Color
Black
Finish
Powder Coated
GTIN
00662620804996
Product UPC
66262080499
Used With
(4) FSP Adapter Panels (Unloaded)

Dimensions

Depth
5.7 in
Height
16.8 in
Length
16.800 in
Thickness
16 GA
Width
14.9 in

Certifications & Compliance

Country of Origin
China
Overview
  • Locking Front Door
  • Conduit Entry Plugs, Top and Bottom
  • Accepts Standard FSP-Series Panels Only
